ACUITY 281L52 100W FieldSET Field-Programmable Outdoor LED Driver

Price $98.68 / EA
Inventory
Available for delivery
Unavailable for pick up Abbotsford
  • Coquitlam
  • Calgary
  • Winnipeg
  • Regina
  • Abbotsford
  • Burnaby
  • Chilliwack
  • Estevan
  • Fort McMurray
  • Kelowna
  • Lethbridge
  • Nanaimo
  • Nisku
  • Penticton
  • PLC Automation
  • Saskatoon
  • Surrey
  • Thunder Bay
  • Trail
  • Victoria
  • Airdrie
  • Edmonton Express
  • LANGLEY
  • Langford Express
  • N. Vancouver Express
  • Red Deer Express
  • Vancouver Express
  • Whistler Express
  • Humboldt
  • Squamish
Qty EA
Manufacturer:ACUITY
Manufacturer #:281L52
Documents Documents

Description

The FieldSET OTI 100W LED Driver is a programmable, dimmable LED driver allowing for replacement of failed drivers in industrial and outdoor luminaries. This programmable driver is compatible with the FieldSET LED Driver Programming Tool which provides visual and audio feedback programming. Replacement for industrial/outdoor drivers. Features an IP66 rated enclosure. Programmable with the FieldSET LED driver handheld programming tool. 0-10V Dimming to 10%.

Specifications

Brand Name eldoLED Sub Brand FieldSET®
Item Name LED Driver Type Constant Current, Field-Programmable, Indoor
Input Voltage 120 - 277 VAC Input Current 0.95 A at 120 V, 0.4 A at 277 V
Output Voltage 30 - 100 VDC Output Current 600 - 1250 mA
Output Power 100 W Frequency Rating 50/60 Hz
Efficiency (%) >=88% at 120 V, >=90% at 277 V Power Factor >0.95
Length 6.61 in Width 2.36 in
Height 1-1/2 in Temperature Rating -40 to 55 °C
Degree of Protection IP66 Environmental Conditions 95% Non-Condensing Humidity, Dry and Damp Rating
Standards CSA Certified, FCC Part 15 Class A, RoHS Compliant, UL E320395 UPC 196183649690

Packages

1 - UNIT - 1 20 - UNIT - 20
